| Brand Name: | JIWEI |
| Model Number: | WP13 |
| MOQ: | 1 |
| Price: | Negotiabce |
| Payment Terms: | T/T |
| Land Based Genset-JW-WP385 | |||||
|---|---|---|---|---|---|
| Gen-set specifications | |||||
| Model | JW-WPG440*8 | ||||
| Standby Rating kVAkWe | 440/352 | ||||
| Prime Rating kVA/kWe | 400/320 | ||||
| Voltage V | 400/230 | ||||
| Frequency Hz | 50 | ||||
| Power Factor | 0.8(lagging) | ||||
| No.of Phases | 3 | ||||
| Fuel consumption@25%/50%/75%(Lh) | 22.2/41.3/60.6 | ||||
| Fuel consumption@100%/110%(Lh) | 82.1/91.2 | ||||
| Sound@1m(dB · (A)) | Open≤105;Silence ≤85 | ||||
| Ambient temp(℃) | -10~45 | ||||
| Gen-set regulation class | ISO8528-5 G2 | ||||
| Steady-state voltage deviation | ≤±2.5% | ||||
| Transient voltage deviation (100%sudden power decrease/increase) |
≤+25%;≤-20% | ||||
| Steady-state frequency band | ≤1.5% | ||||
| Transient frequency deviation from rated frequency (100%sudden power decrease/increase) |
≤+12%;≤-10% | ||||
| Standard Features | |||||
|---|---|---|---|---|---|
| ◆ Electronic governor | ◆DC24 Electric starter | ◆JW-WHC6120NC | |||
| ◆Closed water-cooled | ◆ IP23 | ◆H type insulation | |||
| ◆Air filter | ◆ Muffler | ◆Circuit Breaker | |||
| ◆Startingbatteries | ◆with connective wires | ◆ Radiator | |||
| ◆Oil Drain Valve | ◆Forklift Groove | ◆Shock Absorber | |||
| ◆Color | Weichai blue(B,F)/beige canopy and black chassis(L) | ||||
| ◆Packaging | Wound film packing | ||||
| Options | |||||
|---|---|---|---|---|---|
| ◇Voltage380V/415V | ◇Voltage 440V/480V | ◇Single Voltage 220V/230V | |||
| ◇Automatic Transfer Switch | ◇AutomaticParallel system | ◇PMG | |||
| ◇Engine Heater (water) | ◇Engine Heater(air inlet) | ◇Alternator heater | |||
| ◇External fuel tank(1000L/1500L) | |||||
| Typical Genset Dimensions | ||||||
|---|---|---|---|---|---|---|
| Gmset Model | Prime Rating (kVA) | Length A(mm) | Width B(mm) | Height C(mm) | Wet Weight* (kg) | Standard Fuel tank Capacity (L) |
| JW-WP385/B8 | 400 | 3200 | 1345 | 1885 | 3010 | / |
| JW-WP385/F8 | 400 | 3200 | 1345 | 2025 | 3110 | 450 |
| JW-WP385/L8 | 400 | 4450 | 1400 | 2200 | 3800 | 520 |
We have cooperation with worldwide famous brands. For more specification,please contact us.
![]()
![]()
![]()
![]()
