7 Meters Trailer Lighting Lighthouse 5KW Diesel Generator With 1000W*4 Gold Halide Light

Product Features Overview

Diesel power hand-propelled lighting lighthouse is a kind of diesel generator set as a power source of mobile lighting equipment, the following will be introduced from its structural components, performance characteristics, application scenarios and other aspects:

Structural component

• Lighting system: Usually equipped with multiple high-brightness LED lamp heads or other types of lamps, such as metal halide lamps, can provide high-intensity, large-area lighting.

• Lifting system: common hand, electric and hydraulic, can raise the lamp head to the required height, generally lifting height of 3-9 meters.

• Diesel generator set: composed of diesel engine and generator, to provide power for the lighthouse, the tank capacity is different, generally about 15L-100L, can meet tens of hours of continuous work.

• Walking mechanism: The bottom is equipped with solid tires or universal wheels, easy to push and move, and some are also equipped with rail wheels, which can run on the rail.

• Control system: It is used to control the lifting of the lighthouse, the switch of the lamp head and the Angle adjustment, etc. Some also have the remote control function, which can be operated at a certain distance.

Performance characteristics

• Easy to move: small in size and moderate in weight, the wheel design at the bottom makes it easy to move on all kinds of terrain, and can quickly reach the location that needs lighting.

• Good lighting effect: can provide high brightness, wide range of lighting, light coverage radius up to 30-50 meters, and lamp head can be adjusted separately up and down left and right irradiation Angle.

• Strong ability to adapt to the environment: the whole is made of high-quality metal materials, compact structure, high protection level, generally up to IP65 or more, can work normally in harsh environment and climate conditions.

• Continuous and stable power supply: the power of the diesel generator set is generally between 2KW-15KW, which can be independently generated and supplied without mains power, with strong endurance and can continuously and stably provide power for the lighting system.

Application scenario

• Construction site: Provide sufficient light for construction personnel during night construction at construction sites to ensure construction safety and progress.

• Road construction: In the construction process of road maintenance, expansion, etc., to provide lighting for the construction site, so that the construction personnel can see the work area, but also to provide warnings for passing vehicles and pedestrians.

• Emergency rescue: In emergency situations such as natural disasters and accident rescue, quickly push to the scene to provide lighting support for rescue work and help rescue workers carry out their work.

• Outdoor activities: such as large-scale outdoor performances, sports events, camping and other activities, to meet the lighting needs of the venue and create a good atmosphere.

The following are different models.
