| Brand Name: | JIWEI |
| Model Number: | WP4.1 |
| MOQ: | 1 |
| Price: | Negotiable |
| Payment Terms: | T/T |
Overview
Application scenario
● 100kVA: Suitable for small enterprises, shops, small data centers, etc., as a backup power supply to ensure basic power needs, such as lighting, small office equipment and other power supply.
● 125kVA: can be used in medium-sized shops, small factories, construction sites, etc., can meet some slightly higher power equipment electricity, such as small production equipment, construction machinery, etc.
● 200kVA: often used in large commercial places, medium-sized factories, hospitals, schools, etc., can guarantee key equipment and large-scale power systems, such as medical equipment, teaching buildings, etc.
| Land Based Genset-JW-WP66 | ||||||
| Gen-set specifications | ||||||
| Model | JW-WP66 | |||||
| Standby Rating kVAkWe | 68.5/55 | |||||
| Prime Rating kVAkWe | 62.5/50 | |||||
| Voltage V | 400/230 | |||||
| Frequency Hz | 50 | |||||
| Power Factor | 0.8(lagging) | |||||
| No.of Phases | 3 | |||||
| Fuel consumption@25%/50%/75%(Lh) | 4.34/7.12/9.46 | |||||
| Fuel consumption@100%/110%(Lh) | 13/14.13 | |||||
| Sound@1m(dB · (A)) | Open≤105 dB(A);Silence≤85 dB(A) | |||||
| Ambient temp(℃) | -10~45 | |||||
| Gen-set regulation class | ISO8528-5 G2 | |||||
| Steady-state voltage deviation | ≤±2.5%;≤±5% | |||||
| Transient voltage deviation (100%sudden power decrease/increase) |
+25%;-20% | |||||
| Steady-state frequency band | ≤1.5% | |||||
| Transient frequency deviation from rated frequency (100%sudden power decrease/increase) |
+12%;-10% | |||||
| Standard Features | ||||||
| ◆ Electronic governor | ◆DC24 Electric starter | ◆JW-WHC6120NC | ||||
| ◆Closed water-cooled | ◆ IP23 | ◆H type insulation | ||||
| ◆Air filter | ◆Muffler | ◆Circuit Breaker | ||||
| ◆Startingbatteries | ◆with connective wires | ◆ Radiator | ||||
| ◆Oil Drain Valve | ◆Forklift Groove | ◆Shock Absorber | ||||
| ◆Color | Weichai blue(B,F)/beige canopy and black chassis(L) | |||||
| ◆ Packagng | packing case(B,F) | |||||
| Options | ||||||
| OVoltage380V/415V | OVoltage 440V/480V | ◇Extemal fue tank (1000L/1500L) |
||||
| ◇Single Voltage 220V/230V | OAutomatic Transfer Switch | ◇Altermator heater | ||||
| ◇Engine Heater(water) | ◇PMG/AREP | |||||
| Typical Enclosed Genset Dimensions | ||||||
| Genset Model | Prime Rating (kVA) |
Length A(mm) |
Width B(mm) |
Height C(mm) |
Wet Weight* (kg) |
Standard Fuel tank Capacity (L) |
| JW-WP66B1 | 50 | 1930 | 860 | 1218 | 925 | / |
| JW-WP66F1 | 50 | 1930 | 860 | 1218 | 1030 | 105 |
| JW-WP66L1 | 50 | 2880 | 1050 | 1600 | 1420 | 180 |
| :Include coolantand oil | ||||||
