| Brand Name: | JIWEI |
| Model Number: | WP2.3D25E200 |
| MOQ: | 1 |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Gen-set specifications | |
|---|---|
| Model | JW-WPG25/*1 |
| Standby Rating kVA/kWe | 25/20 |
| Prime Rating kVA/kWe | 22.5/18 |
| Voltage V | 400/440 |
| Frequency Hz | 50/60 |
| Power Factor | 0.8(lagging) |
| No. of Phases | 3 |
| Sound@1m(dB·(A)) | Open≤105 dB(A); Silence ≤85 dB(A) |
| Ambient temp(℃) | -10~45 |
| Gen-set regulation class | ISO8528-5 G2 |
| Steady-state voltage deviation | ≤±2.5%;≤±5% |
| Transient voltage deviation (100%sudden power decrease/increase) | +25%;-20% |
| Steady-state frequency band | ≤1.5% |
| Transient frequency deviation from rated frequency (100%sudden power decrease/increase) | +12%;-10% |
| Fuel consumption@25%/ 50% / 75%(L/h) | 2.4 / 3.9 /5. 3 |
| Fuel consumption@100% / 110%(L/h) | 7.5/ 8.3 |
| Options | |||
|---|---|---|---|
| ◇Voltage380V/415V | ◇Voltage 400V/440V/480V | ◇External fuel tank(1000L/1500L) | |
| ◇Auxiliary winding | ◇Automatic Transfer Switch | ◇Alternator heater | |
| ◇Engine Heater (water) | |||
For detailed parameters, please consult me.
We have cooperation with worldwide famous brands. For more specification,please contact us.
![]()
![]()
![]()
![]()
