| Brand Name: | JIWEI |
| Model Number: | WP6D |
| MOQ: | 1 |
| Price: | Negotiable |
| Payment Terms: | T/T |
Advantage
● Brand and technical strength: Cummins, as the world's leading engine manufacturer, has deep technical accumulation and rich production experience, and its products have undergone strict research and development and testing.
High efficiency and energy saving: It has lower fuel consumption and lower energy consumption in similar engines, which helps to save operating costs.
● Reliable performance: The integrated design avoids the occurrence of engine leakage, fewer parts and lower failure rate, which greatly reduces the comprehensive maintenance cost of the engine.
| Gen-set specifications | |
| Model | JW-WPG137.5/*9 |
| Standby Rating kVA/kWe | 137.5/110 |
| Prime Rating kVAkWe | 125/100 |
| Voltage V | 400/230 |
| Frequency Hz | 50 |
| Power Factor | 0.8(lagging) |
| No.of Phases | 3 |
| Fuel consumption@25%/50%/75%(Lh) | 8.2/14.5/21 |
| Fuel consumption@100%/110%(Lh) | 27/30 |
| Sound@1m(dB · (A)) | Open≤105 dB(A);Silence ≤85 dB(A) |
| Ambient temp(℃) | -10~45 |
| Gen-set regulation class | ISO8528-5 G2 |
| Steady-state voltage deviation | ≤±2.5% |
| Transient voltage deviation (100%sudden power decrease/ncrease) |
≤+25%;≤-20% |
| Steady-state frequency band | ≤1.5% |
| Transient frequency deviation from rated frequency (100%sudden power decrease/increase) |
≤+12%;≤-10% |
| Standard Features | |||||
| ◆ Electronic governor | ◆DC24 Electric starter | ◆JW WHC6120NC | |||
| ◆Closed water-cooled | ◆IP23 | ◆H type insulation | |||
| ◆ Air filter | ◆Muffler | ◆Circuit Breaker | |||
| ◆Startingbatteries | ◆ with connective wires | ◆ Radiator | |||
| ◆Oil Drain Valve | ◆Forklift Groove | ◆Shock Absorber | |||
| ◆ Color | Weichai blue(B,F)/beige canopy and black chassis (L) | ||||
| ◆ Packaging | packing case(B,F) | ||||
| Options | |||||
| ◇Voltage380V/415V | ◇Voltage 440V/480V | ◇Alternator heater | |||
| ◇Single Voltage 220V/230V | ◇Automatic Transfer Switch |
||||
| ◇Engine Heater(water) | ◇Engine Heater (air inlet) | ||||
| ◇External fuel tank(1000L/1500L) | ◇PMG/AREP | ||||
