24kw 220V Silent Diesel Generator Set 30kw Generator Set 3 Phase

Name: 24kw 220V Silent Diesel Generator Set 30kw Generator Set 3 Phase
Brand: Sichuan Jiweicheng Electric Power Equipment Co., Ltd.
SKU: JW-WP40
Price: 2,006.00 USD
Availability: InStock

Brand Name:	JIWEI
Model Number:	JW-WP40
MOQ:	1
Price:	Negotiable
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rated Voltage:

110V/220V/230V/380V/400V/440V,120 To 440V

Frequency:

50/60HZ

Speed:

3600rpm,3000/3600RPM,1500/1800,750n/min,4000

Rated Current:

36A

Rated Power:

24kw，30kva，30kw，37.5kva

Output Type:

AC Single Phase,DC,AC 3 Phase,Other

Color:

Customizable

Engine Type:

WEICHAI，WP6,Air-cooled Diesel Engine,ECU

Starting System:

Recoil Start+Electric Start

Function:

Provide Electric Power

Fuel Tank Capacity:

100L-3000L，According To Customers' Requirement

Alternator Type:

Brush Alternator With AVR Or Brushless With AVR,Three Phase Alternator

Product Name:

24kw 30kw Silent Diesel Generator

Highlight:

24kw Silent Diesel Generator Set

220V Silent Diesel Generator Set

30kw Generator Set 3 Phase

Product Description

24kw 30kw Powerful High Efficiency Super Silent Diesel Generator

Overview

Silent diesel generators are specially designed to minimize noise output, making them ideal for environments where quiet operation is essential. Below are some key features and applications of silent diesel generators.

Key Features

Low Noise Design
- Utilizes soundproof materials and specialized silencers to significantly reduce operational noise.
High Efficiency
- Offers excellent fuel efficiency, providing a stable power output over extended periods.
Durability
- Built with a robust engine structure, capable of enduring long-running and heavy-load conditions.
Portability
- Many models are designed to be mobile, allowing for easy relocation and use in various settings.
Environmental Protection
- Complies with modern environmental standards, minimizing emissions and noise pollution.

Applications

Backup Power Supply
- Serves as an emergency power source during outages, ensuring continuity for critical operations.
Outdoor Activities
- Provides reliable power for events such as weddings, concerts, and outdoor gatherings.
Construction Sites
- Supplies electricity to construction sites lacking access to the electrical grid.
Remote Areas
- Delivers power for research stations, mining operations, and other activities in isolated locations.

Silent diesel generators are a versatile and essential solution for maintaining power in sensitive and varied environments.

Specification

Gen-set specifications
Model	JW-WP40
Standby Rating kVA/kWe	41/33
Prime Rating kVA/kWe	37.5/30
Voltage V	400/230
Frequency Hz	50
Power Factor	0.8(lagging)
No. of Phases	3
Sound@1m(dB·(A))	Open≤105 dB(A); Silence ≤85 dB(A)
Ambient temp(℃)	-10～45
Gen-set regulation class	ISO8528-5 G2
Steady-state voltage deviation	≤±2.5%;≤±5%
Transient voltage deviation (100%sudden power decrease/increase)	+25%；-20%
Steady-state frequency band	≤1.5%
Transient frequency deviation from rated frequency (100%sudden power decrease/increase)	+12%；-10%
Fuel consumption@25%/ 50% / 75%(L/h)	3.2 / 5.4 / 7.9
Fuel consumption@100% / 110%(L/h)	10.5/ 11.6

Standard Features
	♦ Electronic governor	♦DC12 Electric starter	♦ WEICHAI WHC6120NC
	♦ Closed water-cooled	♦ IP23	♦H type insulation
	♦ Air filter	♦ Muffler	♦ Circuit Breaker
	♦Startingatteries	♦ with connective wires	♦ Radiator
	♦Oil Drain Valve	♦Forklift Groove	♦Shock Absorber
	♦ Color	Weichai blue (B,F)/beige canopy and black chassis (L)
	♦ Packaging	packing case(B,F)

Options
	◇Voltage380V/415V	◇Voltage 440V/480V	◇External fuel tank(1000L/1500L)
	◇Auxiliary winding	◇Automatic Transfer Switch	◇Alternator heater
	◇Engine Heater (water)

24kw 220V Silent Diesel Generator Set 30kw Generator Set 3 Phase 0

24kw 220V Silent Diesel Generator Set 30kw Generator Set 3 Phase 1

24kw 220V Silent Diesel Generator Set 30kw Generator Set 3 Phase 2

24kw 220V Silent Diesel Generator Set 30kw Generator Set 3 Phase 3

FAQ

1.Q: What is your MOQ of this item?
A:1 Set2.

2.Q: What is the lead time?

A:7 working days after received the 30%T/T deposit.

3.Q: Is it all right to make customer's own brand name?

A:We can be your OEM manufacture with your authorization of brand.

4.Q: Where is your Loading Port?

A:Shanghai or others.

5.Q: What are your payment terms?

A:30% TT as deposit,70% TT before Shipment.

6.Q: What is your company's available production capacity?

A:100 Sets per month.

7.Q:What's the warranty time of diesel generators?

A:12 months or 1000 working hours, whichever comes first.
