High Power Genset Silent Type Soundproof 187.5kva Generator 150 Kw Diesel

Name: High Power Genset Silent Type Soundproof 187.5kva Generator 150 Kw Diesel
Brand: Sichuan Jiweicheng Electric Power Equipment Co., Ltd.
SKU: JW-WP185
Price: 2,006.00 USD
Availability: InStock

Brand Name:	JIWEI
Model Number:	JW-WP185
MOQ:	1
Price:	Negotiable
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rated Voltage:

220V,110V/220V/230V/240V/380V,120 To 440V Optional,110V / 240V,110v/220v

Frequency:

50/60HZ,50HZ,50HZ / 60HZ,50,50HZ Or 60HZ

Speed:

3600rpm,3000/3600RPM,1500/1800,750n/min,4000

Rated Current:

9A,8.3A,9.1A,26A,2A To 55A

Rated Power:

150KW，187.5KVA

Output Type:

AC Single Phase,DC,AC 3 Phase,Other

Color:

Customizable

Engine Type:

WEICHAI，WP7,Air-cooled Diesel Engine,ECU

Starting System:

Recoil Start+Electric Start

Fuel:

Diesel Oil

Function:

Provide Electric Power

Fuel Tank Capacity:

100L-1000L

Alternator Type:

Brush Alternator With AVR Or Brushless With AVR,Three Phase Alternator

Oem:

Available,Accepted

Product Name:

Silent 150kw 187.5kva Diesel Generator

Highlight:

High power genset silent type

super quiet diesel generator 187.5kva

100L tank generator 150 kw diesel

Product Description

High-power Soundproof 150kw 187.5kwa Silent Diesel Generator

Overview

High Power Output: This 150KW diesel generator delivers a reliable power output of 150KW, making it an ideal solution for commercial and industrial applications, including data centers, hospitals, and manufacturing facilities.
Durable Construction: With a corrosion-resistant design and high-temperature capabilities, this generator is built to withstand harsh environments and provide long-lasting performance.
Advanced Starting System: The auto-start feature ensures seamless and efficient startup, reducing downtime and increasing productivity.
Comprehensive Warranty: With a 1-year warranty and 3000 running hours, customers can have peace of mind knowing they are protected against defects and performance issues.

Specification

Gen-set specifications
Model	JW-WP185
Standby Rating kVA/kWe	206/165
Prime Rating kVA/kWe	187.5/150
Voltage V	440/400/380/230
Frequency Hz	50/60
Power Factor	0.8(lagging)
No. of Phases	3
Sound@1m(dB·(A))	Open≤105 dB(A); Silence ≤85 dB(A)
Ambient temp(℃)	-10～45
Gen-set regulation class	ISO8528-5 G2
Steady-state voltage deviation	≤±2.5%
Transient voltage deviation (100%sudden power decrease/increase)	≤+25% ；≤-20%
Steady-state frequency band	≤1.5%
Transient frequency deviation from rated frequency (100%sudden power decrease/increase)	≤+12%；≤-10%

Standard Features
	♦ ECU	♦DC24 Electric starter	♦JW- WHC6120CAN
	♦ Closed water-cooled	♦ IP23	♦H type insulation
	♦ Air filter	♦ Muffler	♦ Circuit Breaker
	♦Startingbatteries	♦ with connective wires	♦ Radiator
	♦Oil Drain Valve	♦Forklift Groove	♦Shock Absorber
	♦ Color	Weichai blue (B,F)/beige canopy and black chassis (L)
	♦ Packaging	packing case(B,F)

Options
	◇Voltage380V/415V	◇Voltage 440V/480V	◇Automatic Parallel system
	◇Single Voltage 220V/230V	◇Automatic Transfer Switch	◇Alternator heater
	◇Engine Heater (water)	◇Engine Heater (air inlet)
	◇External fuel tank(1000L/1500L)	◇PMG/AREP

High Power Genset Silent Type Soundproof 187.5kva Generator 150 Kw Diesel 0

High Power Genset Silent Type Soundproof 187.5kva Generator 150 Kw Diesel 1

High Power Genset Silent Type Soundproof 187.5kva Generator 150 Kw Diesel 2

High Power Genset Silent Type Soundproof 187.5kva Generator 150 Kw Diesel 3

FAQ

1.Q: What is your MOQ of this item?
A:1 Set2.

2.Q: What is the lead time?

A:7 working days after received the 30%T/T deposit.

3.Q: Is it all right to make customer's own brand name?

A:We can be your OEM manufacture with your authorization of brand.

4.Q: Where is your Loading Port?

A:Shanghai or others.

5.Q: What are your payment terms?

A:30% TT as deposit,70% TT before Shipment.

6.Q: What is your company's available production capacity?

A:100 Sets per month.

7.Q:What's the warranty time of diesel generators?

A:12 months or 1000 working hours, whichever comes first.
